POMP CENTRIFUGAAL WEG AL80-04 0,75kW
| General | |
|---|---|
| Item number | 15.36.AL.01 |
| Material | Cast Iron |
| Number | 1 |
| Weight (kg) | 40 |
| Condition | Used |
| Type plate manufacturer | Yes |
| Manufacturer | WEG |
| Year Built | 2009 |
| Design Code | AL80-04 |
| Construction data available | No |
| Working temperature (° C) | 40 |
.jpg)
.jpg)
.jpg)
.jpg)
| Dimensions | |
|---|---|
| Total height (mm) | 200 |
| Length (mm) | 700 |
| Width (mm) | 300 |
| Remarks | |
|---|---|
| Description (EN) | merk : WEG • typ: AL80-04 • 30 june 09 1004838141 • 220/380V - 50Hz - 0,75 kW - 1380/min - 3,25/1,88 A - cos phi 0,84 • 230/400V - 50 Hz - 0,75kW - 1395/min - 3,23/1,86 A - cos phi 0,81 • 415V - 50Hz - 0,75kW - 1405/min - 1,93 A - cos phi 0,76 • 440/460 V - 60hz - 0,85 kW - 1685/1700/min - 1,82/1,83A - cos phi 0,8 316F • réf. M3M6FPPX • F350729/5 |
