Used silo
- Material: Aluminium
- Condition: Used
- Volume (in litres): 65000 L
- In stock: 1
| General | |
|---|---|
| Item number | 04.45.KE.27 |
| Material | Aluminium |
| Number | 1 |
| Capacity (Liters) | 65000 |
| Type tank | Silo |
| Fixation | Skirt |
| Model of the tank | Vertical |
| Shape of the tank | Cylindrical |
| Bottom | Conical bottom |
| Tank model | Single wall |
| Number lifting lugs | 2 |
| Density (kg/dm³) | 1,3 |
| Number of manhole | 1 |
| Position of manhole (s) | Top |
| Dimensions of manholes | dia 585mm |
| Tank with total drain? | Yes |
| Type of outlet (s) | man. schuifafsluiter |
| Diameter of outlet (mm) | DN250 |
| locality | B-7711 Belgium |
| Provision tank cleaning | None |
| Weight (kg) | 2150 |
| Condition | Used |
| Type plate manufacturer | Yes |
| Manufacturer | Ellimetal |
| Year Built | 2007 |
| Top side | |
|---|---|
| Configuration top-side | Closed |
| Detail closed top side | Conical bottom |
| Dimensions | |
|---|---|
| Cylinder Thickness (mm) | 3,7 |
| Bottom thickness (mm) | 4,4 |
| Periphery (mm) | 9450 |
| Cylindrical length (mm) | 8500 |
| Slope bottom (°) | 30 |
| Height bottom (mm) | 2500 |
| Total height (mm) | 13900 |
| Length (mm) | 3230 |
| Diameter tank (mm) | 3000 |
| Width (mm) | 3230 |
| Insulation | |
|---|---|
| Insulation | No |
| Remarks | |
|---|---|
| Description (EN) | Working pressure: ATM --- Working temperature: AMB --- cage ladder not available --- filler tube not available |
