Used silo
- Material: Aluminium
- Condition: Used
- Volume (in litres): 55000 L
- In stock: 1
| General | |
|---|---|
| Item number | 04.39.NE.01 |
| Material | Aluminium |
| Number | 1 |
| Capacity (Liters) | 55000 |
| Type tank | Silo |
| Fixation | Skirt |
| Model of the tank | Vertical |
| Shape of the tank | Cylindrical |
| Bottom | Conical bottom |
| Tank model | Single wall |
| Number lifting lugs | 2 |
| Density (kg/dm³) | 1 |
| Number of manhole | 2 |
| Position of manhole (s) | Top and Cylindrical part |
| Dimensions of manholes | 600 - 750 |
| Tank with total drain? | Yes |
| Type of outlet (s) | flens |
| Diameter of outlet (mm) | 250 x 250 |
| locality | B-7711 Belgium |
| Provision tank cleaning | None |
| Weight (kg) | 1950 |
| Condition | Used |
| Top side | |
|---|---|
| Configuration top-side | Closed |
| Detail closed top side | Conical bottom |
| Dimensions | |
|---|---|
| Cylinder Thickness (mm) | 4 |
| Periphery (mm) | 9450 |
| Cylindrical length (mm) | 7500 |
| Slope bottom (°) | 35 |
| Height bottom (mm) | 1700 |
| Total height (mm) | 11250 |
| Diameter tank (mm) | 3000 |
| Insulation | |
|---|---|
| Insulation | No |
| Remarks | |
|---|---|
| Description (EN) | thickness varies from 4.5 mm at the bottom to 3 mm at the top |
