Used storage tank
- Material: Stainless steel 304
- Condition: Used
- Volume (in litres): 25000 L
- In stock: 1
| General | |
|---|---|
| Item number | 03.46.WE.03 |
| Material | Stainless steel 304 |
| Finishing weldings inside | Grinded |
| Number | 1 |
| Capacity (Liters) | 25000 |
| Type tank | Storage tank |
| Fixation | 4 legs |
| Model of the tank | Vertical |
| Shape of the tank | Cylindrical |
| Bottom | Dished bottom |
| Tank model | Single wall |
| Number lifting lugs | 2 |
| Number of manhole | 1 |
| Position of manhole (s) | cylindrical part |
| Dimensions of manholes | 350*450 |
| Tank with total drain? | Yes |
| Type of outlet (s) | flens |
| Diameter of outlet (mm) | 100 |
| locality | On location |
| Last application | Food |
| Provision tank cleaning | CIP ball |
| Condition | Used |
| Type plate manufacturer | Yes |
| Manufacturer | SIELMANN Bremen |
| Year Built | 2007 |
| Construction data available | No |
| Top side | |
|---|---|
| Configuration top-side | Closed |
| Detail closed top side | Dished bottom |
| Thickness closed dome (mm) | 2,2 |
| Dimensions | |
|---|---|
| Cylinder Thickness (mm) | 2,5 |
| Bottom thickness (mm) | 2,2 |
| Cylindrical length (mm) | 4500 |
| Height bottom (mm) | 550 |
| Outside diameter tank (mm) | 2690 |
| Total height (mm) | 6200 |
| Diameter tank (mm) | 2490 |
| Insulation | |
|---|---|
| Insulation | Yes |
| Performance insulation | Fully insulated |
| Type of insulation | Insulating wool |
| Thickness (mm) | 50 |
| Finishing insulation | Profile Cladding |
| Insulation material | galvanised |
