Used storage tank
- Material: Stainless steel 304
- Condition: Used
- Volume (in litres): 20000 L
- In stock: 1
| General | |
|---|---|
| Item number | 03.46.NA.01 |
| Material | Stainless steel 304 |
| Finishing weldings inside | Grinded |
| Number | 1 |
| Capacity (Liters) | 20000 |
| Type tank | Storage tank |
| Fixation | 6 legs |
| Model of the tank | Vertical |
| Shape of the tank | Cylindrical |
| Bottom | Inclined bottom |
| Tank model | Single wall |
| Number of manhole | 1 |
| Position of manhole (s) | Top |
| Dimensions of manholes | 500 |
| Tank with total drain? | Yes |
| Type of outlet (s) | Nipple |
| Diameter of outlet (mm) | 50 |
| locality | B-7711 Belgium |
| Provision tank cleaning | None |
| Weight (kg) | 2800 |
| Condition | Used |
| Type plate manufacturer | No |
| Construction data available | No |
| Top side | |
|---|---|
| Configuration top-side | Closed |
| Detail closed top side | Conical bottom |
| Dimensions | |
|---|---|
| Cylindrical length (mm) | 3500 |
| Outside diameter tank (mm) | 2880 |
| Total height (mm) | 5690 |
| Diameter tank (mm) | 2800 |
| Insulation | |
|---|---|
| Insulation | Yes |
| Performance insulation | cylinder and bottom isolated |
| Finishing insulation | Rivited sheet cladding |
| Insulation material | Steel |
| Remarks | |
|---|---|
| Description (EN) | Inner cylindrical height 3200 mm, outer wall and feet in painted steel |
