Used mixing vessel
- Material: Stainless steel 316
- Condition: Used
- Volume (in litres): 1100 L
- In stock: 1
| General | |
|---|---|
| Item number | 03.42.SI.02 |
| Material | Stainless steel 316 |
| Finishing weldings inside | Grinded |
| Number | 1 |
| Capacity (Liters) | 1100 |
| Type tank | Mixing vessel |
| Fixation | 4 legs |
| Model of the tank | Vertical |
| Shape of the tank | Cylindrical |
| Bottom | Dished bottom |
| Tank model | Single wall |
| locality | B-7711 Belgium |
| Provision tank cleaning | None |
| Condition | Used |
| Top side | |
|---|---|
| Configuration top-side | Partly open |
| Detail top side | 2x flap lid |
| Thickness of top side (mm) | 2 |
| Dimensions | |
|---|---|
| Cylinder Thickness (mm) | 2 |
| Bottom thickness (mm) | 3 |
| Periphery (mm) | 3014 |
| Cylindrical length (mm) | 1250 |
| Total height (mm) | 2400 |
| Diameter tank (mm) | 960 |
| Width (mm) | 1090 |
| Insulation | |
|---|---|
| Insulation | No |
| Agitators | |
|---|---|
| Number of agitators | 1 |
| Agitator 1: Type | anchor with scrapers |
| Agitator 1: Position | Centrally on the top |
| Agitator 1: Atex/Ex? | No |
| Remarks | |
|---|---|
| Description (EN) | motor with reduction - ( motor manufacturor NORD type SK90SH/4 - IP55-230/400V-1.1kW-4.19/2.42A-50/60KZ - 1435rpm(50HZ) - 1745rpm( 60HZ) IE2 81.4%( 50HZ) - IE2 84%( 60HZ) ) - reductor NORD (M2 552NM-P 1.1kW-i=1234.42) -top2xBSP2" conections -bottom BSP 2" exhaust |
